Note:

The current version KM RC Model Universal AfterBurner is now compatible with the Avian thrust-reversing ESC. To work with Avian Smart ESC. Do not connect the afterburner to throttle channel with Y lead. Unplug the Avian Smart ESCs' throttle lead from ch1, plug it in the "bind/prog" port for normal throttle control. Then use the "throttle port/ch1" to control the burner.

Please test all functions before connecting to the model airplane. And provide enough cooling when testing.

The current version KM RC Model Universal AfterBurner is designed to use with a 6S single battery circuit. If you would like to use our unit for batteries in series. Please make sure you only connect the balance lead to battery A as shown below.

All KM RC Model AfterBurners come with mounting fits for easy Out Runner Motor modification. Please check this video for the detailed Out Runner Motor Fit:

https://www.youtube.com/watch?v=pp8-UjK1SS4

Have questions? Find frequently asked questions on the product page. Or send an E-mail through Contact us tab.
